Carbon Fiber Reinforced Polymer
Sample Information
This sample was obtained from the research team of Shi Xuetao, the Advanced Materials Research Laboratory of Northwestern Polytechnical University. It was originally a sample of material performance test prepared by Hexcel Composites. Its size is 11x17 cm2, which is a two-way braided structure. We did a simple cropping operation later on.
Introduction
Carbon fiber reinforced polymer, carbon fiber reinforced plastic, or carbon fiber reinforced thermoplastic (CFRP, CRP, CFRTP), is an extremely strong and light fiber-reinforced plastic which contains carbon fibers. CFRPs can be expensive to produce but are commonly used wherever high strength-to-weight ratio and stiffness (rigidity) are required, such as aerospace, superstructure of ships, automotive, civil engineering, sports equipment, and an increasing number of consumer and technical applications.
Literature Review
Carbon fiber refers to an inorganic polymer material having a carbon content of 90% or more by decomposition and carbonization by subjecting an organic fiber such as polypropylene or asphalt to high temperature (1000 ° C to 3000 ° C) under an inert gas atmosphere. Carbon fiber has excellent properties of high electrical conductivity, corrosion resistance, wear resistance, high-temperature resistance, and lightweight. Its excellent mechanical properties are unmatched by steel and other alloy metals. Although its specific gravity is only one-quarter of that of steel, its tensile strength can reach 7 times that of steel. In addition, carbon fiber is also highly resistant to corrosion and shock absorption. It is widely used in aerospace, automotive wind power, medical equipment, building reinforcement, and petrochemical industries. The promotion of carbon fiber further promotes the rapid development of the global economy and industrial civilization. It is also known as “black gold” in the world.
Processing and Manufaction
Abstract
This study investigated in detail the various properties and applications of carbon fiber materials and consulted the relevant literature on this basis to further explore the carbon fiber production process and production process and contacted the relevant manufacturers to obtain the material safety information sheet, completed this species’ material library webpage construction. The research of this project will enrich the content of the materials library and provide a basic data summary and further database and literature information summary for engineers or students who need this information.
Classification
Reflection
In the process of making posters, how to properly display the performance, structure and application of materials is the biggest problem in the whole process. The presentation form of the four elements of the material not only comprehensively includes the information of all aspects of the material, but also makes the structure of the whole poster more reasonable and more logical.
References
Zhang Jian, Chuai Xuebing. Development of carbon fiber and its application status [J]. Chemical management,2017(23):60.
Zhao Suilin, Lu Ying. Development of carbon fiber and its application status [J]. Guide to knowledge,2016(01):44.
Zhang Dingjin, Chen Hong and Zhang Jing. Current status and development trend of carbon fiber and its composite materials industry at home and abroad [J]. New materials industry,2015(05):31-35.
Tang Jia, Chen Yuxiang. Carbon fiber research and development status [J]. Chemical design communication,2017,43(10):63.
Gallaire, F., Gmür, T., Leterrier, Y. and Schorderet, A. (2019). A Novel Structural Health Monitoring Method for Full-Scale CFRP Structures. [online] Infoscience.epfl.ch. Available at: https://infoscience.epfl.ch/record/206768/files/EPFL_TH6422.pdf [Accessed 26 Mar. 2019].
Jérôme, P. (2019). Composite Materials in the Airbus A380 - From History to Future -. [online] Iccm-central.org. Available at: http://www.iccm-central.org/Proceedings/ICCM13proceedings/SITE/PAPERS/paper-1695.pdf [Accessed 26 Mar. 2019].
Kopeliovich, D. (2019). Carbon Fiber Reinforced Polymer Composites [SubsTech]. [online] Substech.com. Available at: http://www.substech.com/dokuwiki/doku.php?id=carbon_fiber_reinforced_polymer_composites [Accessed 26 Mar. 2019].
Qi Ying. Development status of carbon fiber and its composite materials [J]. New materials industry,2017(12):2-6.
Cai Wenfeng, Zhou Huiqun, Yu Fengli. Current Status and Development Direction of Resin-Based Carbon Fiber Composites [J]. Aviation manufacturing technology,2008(10):54-57.
Hexcel.com. (2019). Hexcel | Composite Materials and Structures. [online] Available at: https://www.hexcel.com/ [Accessed 25 Mar. 2019].
Yang Qiangqiang -Research on the quality improvement of advanced pultrusion products process，2017.
Murat seman-Monitoring of part Dimensions and fiber content in vacuum assisted resin transfer molding(VARTM) Process ,2007.
